4.1 - Physical data 30XAV-ZE
30XAV-ZE 401 501 551 651 701 851 901
Sound levels
Standard unit
Sound power level*** dB(A) 102 103 103 103 105 106 106
Sound pressure level at 10 m**** dB(A) 70 70 70 70 72 73 73
Standard unit + option 279*
Sound power level*** dB(A) 99 100 100 100 102 103 103
Sound pressure level at 10 m**** dB(A) 67 68 68 67 69 70 70
Standard unit + option 257*
Sound power level*** dB(A) 96 97 97 97 99 100 100
Sound pressure level at 10 m**** dB(A) 63 65 64 64 66 67 67
Dimensions - Standard unit
Length mm 6092 6092 7186 8380 9573 10767 11962
Width mm 2253 2253 2253 2253 2253 2253 2253
Height mm 2297 2297 2297 2297 2297 2297 2297
Operating Weight**
Standard unit kg 4831 5219 5767 6420 6806 7687 8076
Compressors
Circuit A 1 1 1 1 1 1 1
Circuit B 1 1 1 1 1 1 1
Refrigerant** R1234ze(E)
Circuit A kg 50 52 56 64 79 80 84
teqCO
2
0.1 0.1 0.1 0.1 0.1 0.1 0.1
Circuit B kg 43 54 58 67 71 82 87
teqCO
2
0.1 0.1 0.1 0.1 0.1 0.1 0.1
Oil charge
Circuit A 24 24 24 24 30 29 28
Circuit B 21 24 24 24 24 29 28
Capacity control Touch Pilot control
Minimum capacity***** % 10 10 10 10 10 10 10
Condensers All aluminium Micro Channel Heat Exchanger (MCHE)
 Axial FLYING-BIRD IV fans with rotating shroud
Quantity 9 10 12 14 16 18 20
Maximum total air ow l/s 40608 45120 54144 63168 72192 81216 90240
Maximum rotational speed rps 15.7 15.7 15.7 15.7 15.7 15.7 15.7
Evaporator Flooded multi-pipe type
Water volume l 75 90 90 110 120 134 146
Max water-side operating pressure 1000 1000 1000 1000 1000 1000 1000
Hydronic module Victaulic type
Diameter inch 5 6 6 6 6 8 8
Outside tube diameter mm 141.3 168.3 168.3 168.3 168.3 219.1 219.1
Chassis paint colour
Colour code: RAL7035
* Options: 257 = low sound level, 279 = compressor enclosure
** Values are guidelines only. Refer to the unit nameplate.
*** In dB ref=10
-12
W, (A) weighting. Declared dualnumber noise emission values in accordance with ISO 4871 (with an associated uncertainty of +/-3dB(A)). Measured in accordance with ISO 9614-1
and certied by Eurovent.
**** In dB ref 20 μPa, (A) weighting. Declared dualnumber noise emission values in accordance with ISO 4871 (with an associated uncertainty of +/-3dB(A)). For information, calculated from the sound
power level Lw(A).
***** For standard conditions. Depending on operating conditions, unit might have a dierent minimum capacity or cycle.
