PERFORMANCE DATA (cont)
ELECTRICAL DATA FOR UNITS WITH FACTOR Y--INSTALLED HEATERS (cont)
MODEL NO
MTR
HP
MTR
FLA
HEAT PACK
INSTALLED
SINGLE CIRCUIT DUAL CIRCUIT
HTR
AMPS
MCA
MAX
OVERCUR
PROTECT
HTR
AMPS
MCA
MAX
OVERCUR
PROTECT
HTR
AMPS
MCA
MAX
OVERCUR
PROTECT
L1/L2 L1/L2 L1/L2 L3/L4 L3/L4 L3/L4
FA4CNB060010 3/4 5.2 MKFCEH0901N10 36.2/40.0 51.8/56.5 50/60 --- --- --- --- --- ---
FA4CNB060015 3/4 5.2 MK FCEH1501F15 54.2/59.9 74.3/81.4 80/80 36.2/40.0 51.8/56.5 60/60 18.1/20.0 22.6/25.0 25/25
FA4CNC018005 1/6 1.8 MKFCEH0501N05 18.1/20.0 24.9/27.3 25/ 30 --- --- --- --- --- ---
FA4CNC024005 1/4 1.8 MKFCEH0501N05 18.1/20.0 24.9/27.3 25/ 30 --- --- --- --- --- ---
FA4CNC030008 1/4 1.5 MKFCEH0801N08 28.9/32.0 38.0/41.9 40/ 45 --- --- --- --- --- ---
FA4CNC036010 1/3 2.4 MKFCEH0901N10 36.2/40.0 48.3/53.0 50/ 60 --- --- --- --- --- ---
FA4CNC042010 1/2 2.9 MKFCEH0901N10 36.2/40.0 48.9/53.6 50/ 60 --- --- --- --- --- ---
FA4CNC048010 3/4 4.3 MKFCEH0901N10 36.2/40.0 50.6/55.4 50/ 60 --- --- --- --- --- ---
FA4CNC060010 3/4 5.2 MKFCEH0901N10 36.2/40.0 51.8/56.5 50/ 60 --- --- --- --- --- ---
FA4CNF018005 1/6 1.8 MKFCEH0501N05 18.1/20.0 24.9/27.3 25/30 --- --- --- --- --- ---
FA4CNF018008 1/6 1.8 MKFCEH0801N08 28.9/32.0 38.4/42.3 40/45 --- --- --- --- --- ---
FA4CNF024005 1/4 1.8 MKFCEH0501N05 18.1/20.0 24.9/27.3 25/30 --- --- --- --- --- ---
FA4CNF024010 1/4 1.8 MKFCEH0901N10 36.2/40.0 47.5/52.3 50/60 --- --- --- --- --- ---
FA4CNF030008 1/4 1.5 MKFCEH0801N08 28.9/32.0 38.0/41.9 40/45 --- --- --- --- --- ---
FA4CNF030010 1/4 1.5 MKFCEH0901N10 36.2/40.0 47.1/51.9 50/60 --- --- --- --- --- ---
FA4CNF036010 1/3 2.4 MKFCEH0901N10 36.2/40.0 48.3/53.0 50/60 --- --- --- --- --- ---
FA4CNF036015 1/3 2.4 MKFCEH1501F15 54.2/59.9 70.8/77.9 80/80 36.2/40.0 48.3/53.0 50/60 18.1/20.0 22.6/25.0 25/25
FA4CNF042010 1/2 2.9 MKFCEH0901N10 36.2/40.0 48.9/53.6 50/60 --- --- --- --- --- ---
FA4CNF042015 1/2 2.9 MKFCEH1501F15 54.2/59.9 71.4/78.5 80/80 36.2/40.0 48.9/53.6 50/60 18.1/20.0 22.6/25.0 25/25
FA4CNF048010 3/4 4.3 MKFCEH0901N10 36.2/40.0 50.6/55.4 50/60 --- --- --- --- --- ---
FA4CNF048015 3/4 4.3 MKFCEH1501F15 54.2/59.9 73.1/80.3 80/80 36.2/40.0 50.6/55.4 60/60 18.1/20.0 22.6/25.0 25/25
NOTE: All u nits 208/230, single---pha se, 60 Hz
MCA --- Minimum Circuit Amps
FLA --- Fu l l L o a d Am p s
ELECTRICAL DATA FOR UNITS WITHOUT FACT ORY--INSTALLED HEATERS
MODEL NO
MTR
HP
MTR
FLA
MCA
MAX
OVERCUR
PROTECT
MIN WIRE
SIZE AWG*
FY4ANB060T00
3/4 5.2 6.5 15 14
FY4ANB060000
FY4ANF018T00
1/6 1.8 2.3 15 14
FY4ANF018000
FY4ANF024T00
1/4 1.8 2.3 15 14
FY4ANF024000
FY4ANF030T00
1/4 1.5 1.9 15 14
FY4ANF030000
FY4ANF036T00
1/3 2.4 3.0 15 14
FY4ANF036000
FY4ANF042T00
1/2 2.9 3.6 15 14
FY4ANF042000
FY4ANF048T00
3/4 4.3 5.4 15 14
FY4ANF048000
MODEL NO
MTR
HP
MTR
FLA
MCA
MAX
OVERCUR
PROTECT
MIN WIRE
SIZE AWG*
FA4CNB060000 3/4 5.2 6.5 15 14
FA4CNF018000 1/6 1.8 2.3 15 14
FA4CNF024000 1/4 1.8 2.3 15 14
FA4CNF030000 1/4 1.5 1.9 15 14
FA4CNF036000 1/3 2.4 3.0 15 14
FA4CNF042000 1/2 2.9 3.6 15 14
FA4CNF048000 3/4 4.3 5.4 15 14
* Usecopperwireonly.Use75_C only in this application. When using non ---metallic (NM) sheathed cable, wire size required should be based on that of
60
_C conductors, instead of wire sizes shown in table above per NEC Article 336 ---26.
NOTES: If branch circuit wire length exceeds 100 ft. (30m), consult NEC 215---2 to determine maximum wire length. Use 2% voltage drop.
All un its 208/230, single ---phase, 60 Hz.
FLA --- Fu l l L o a d Am p s
FACTORY--INSTALLED HEATER OPTIONS*
MODEL 018 024 030 036 042 048 060
FA4CN(F,B) 5, 8 5, 10 8, 10 10, 15 10, 15 10, 15 10, 15
FA4CNC 5 5 8 10 10 10 10
FY4AN(F,B) 5, 8 5, 10 8, 10 10, 15 10, 15 10, 15 10, 15
* For field---install ed heater/fan coil combina tions, see Electric Heater Interna l Protection below.
6th dig it: B --- M o d u l a r ca b i n e t , C --- D i s c o n n e c t , F --- S i n g l e p i e c e c a b i n e t
ELECTRIC HEATER INTERNAL PROTECTION*
HEATER KW PHASE FUSE QTY/SIZE CKT BKR QTY/SIZE{
3 1 — —
5 1 — 1/60
8 1 — 1/60
10 1 — 1/60
15 1 2/30 — 2/60 2/60
20 1 4/60 2/60
24 1/3 6/60 —
30 1/3 6/60 —
9 1/3 — —
15 3 — —
18 3 — —
* 5 --- , 8 --- , 1 0 --- k W f a c t o r y --- i n s t a l l e d h e a t h a s n o i n t e r n a l pr o t e c t i o n . 15 --- k W f a c t o r y --- i n s t a l l e d h e a t i s i n t e r n a l l y p r o t e c t e d wi t h f u s e s .
{ Circuit breakers are 2 pole.
FY4A / FA4C
