ACCESSORIES
ITEM ACCESSORY PART NO.* FAN COIL SIZE USED WITH
1. Disconnect Kit KFADK0201DSC Cooling controls and heaters 3--- through 10---kW
2. Downflow Base Kit
KFACB0101CFB 018
KFACB0201CFB 024, 030
KFACB0301CFB 036, 042, 048
KFACB0401CFB 060
3. Downflow Conversion Kit
KFADC0201SLP Slope Coil Units—018, 024, 030, 036
KFADC0401ACL A---Coil Units—042, 048, 060
4. Single--- Point Wiring Kit KFASP0101SPK O n l y w i t h 1 5 --- a n d 2 0 --- k W Fu s e d H e a t e r s
5. Filter Kit (12 Pack)
KFAFK0112SML 018
KFAFK0212MED 024, 030
KFAFK0312LRG 036, 042, 048
KFAFK0412XXL 060
6. PVC Condensate Trap Kit (50 pack) KFAET0150ETK All
7. Air Cleaner 240--- volt Conversion Kit KEAVC0201240 All
8. Downflow/Horizontal Conversion Gasket Kit KFAHD0101SLP All
9. Horizontal Water Management Kit (25 pack) KFAHC0125AAA All
* Factory authorized and listed, field---installed.
ACCESSORY KITS DESCRIPTION SUGGESTED AND REQUIRED USE.
1. Disconnect Kit
The kit is used to disconnect electrical power to the fan coil so service or maintenance may be performed safely.
SUGGESTED USE: Units for 3-- through 10 --kW electric resistance heaters and cooling controls.
2. Downflow Base Kit
This kit is designed to provide a 1 --in. minimum clearance between unit discharge plenum, ductwork, and combustible materials. It
also provides a gap-- free seal with the floor.
REQUIRED USE: This kit must be used whenever fan coils are used in downflow applications.
3. Downflow Conversion Kit
Fan coils are shipped from the factory for upflow or horizontal--left applications. Downflow conversion kits provide proper condensate
water drainage and support for the coil when used in downflow applications. Separate kits are available for slope coils and A--coils.
REQUIRED USE: This kit must be used whenever fan coils are used in downflow applications.
4. Single Point Wiring Kit
The single point wiring kit acts as a jumper between L1 and L3 lugs, and between the L2 and L4 lugs. This allows the installer to run
two heavy-- gauge, high-- voltage wires into the fan coil rather than 4 light--gauge, high-- voltage wires.
SUGGESTED USE: Fan coils with 15-- and 20--kW fused heaters only.
5. Filter Kit (12 pack)
The kit consists of 12 fan coil framed filters. These filters collect large dust particles from the return air entering the fan coil and
prevents them from collecting on the coil. This process helps to keep the coil clean, which increases heat transfer and, in turn, the
efficiency of the system.
SUGGESTED USE: To replace filters in fan coils.
REQUIRED USE: All units unless a filter grille is used.
6. Condensate Drain Trap Kit
This kit consists of 50 PVC condensate traps. Each trap is pre--formed and ready for field installation. This deep trap helps the system
make and hold proper condensate flow even during blower initiation.
SUGGESTED USE: All fan coils.
7. Air Cleaner 240--volt Conversion Kit
The AIRA electronic air cleaner comes ready for 115--v operation.
REQUIRED USE: This kit is required when running 240 -- volt circuit to air cleaner.
8. Downflow/Horizontal Conversion Gasket Kit
This kit provides the proper gasketing of units when applied in either a downflow or horizontal application.
REQUIRED USE: Fan coils in either downflow or horizontal applications.
9. Horizontal Applications -- Water Management Kit
This kit provides proper installation of fan coils under conditions of high static pressure and high relative humidity.
SUGGESTED USE: All fan coils.
Copyright 2007 Carrier Corp. S 7310 W. Morris St. S Indianapolis, IN 46231 Printed in U.S.A. Edition Da te: 06/07
Manufacturer reserves the right to change, at any time, specifications and designs without notic e and without obligations.
Catalog No: FA4C---5PD
Replaces: FA4C--4PD
