— 41 —
Notes:
1. Price and specifications are subject to change without notice.
2. As for order / supply of spare parts, refer to the “GUIDE BOOK for spare parts supply” a separate
publication
3. The numbers in the item column correspond to the same numbers in exploded drawing.
4. MARKS:
Q: Quantity used per unit
R: Rank
A: Essential
B: Stock recommended
C: Less recommended
X: No stock recommended
10. Parts list (200CR/PCR-360/PCR-365)
1. MAIN PCB BLOCK
2. UPPER CASE BLOCK
3. MAIN DISPLAY BLOCK
4. CUSTOMER DISPLAY BLOCK
5. KEYBOARD BLOCK
6. POWER SUPPLY BLOCK
7. LOWER CASE BLOCK
8. PRINTER BLOCK
9. WIND MOTOR BLOCK
10. PRINTER COVER BLOCK
11. OTHERS
12. DRAWER
12-1. DL-1320 (U.S.)
12-2. DL-2762 (Europe, U.K., Germany, other countries)
