E
8
General Guide
Press to turn on
power.
Press to turn off
power.
Keyboard
Display
Cassette cover
Open this cover to
load or remove the
ink ribbon cassette.
Slit
Slide the
disc to be
printed into
the slit.
USB port
For connection of a USB cable when
exchanging data with a computer.
AC adaptor terminal
Connect the
AC adaptor here.
Battery cover
If you cannot remove the disc from the printer due to printer malfunction, try
performing the following steps to remove the disc.
1 Press OFF.
2 While holding down the D and H keys, press ON.
If you are still unable to remove the disc after performing the above
operations, perform the following steps to remove the disc from the printer.
Normally, you should not use the following procedure to release the print
head. Use this procedure only when the print head fails to release normally
due to malfunction.
Print Head Release Button Hole
To Next Page
