— 71 —
Notes: 1. The numbers in the item column correspond to the same numbers in exploded view.
2. MARKS:
Q:Quantity used per unit
R:Rank A: Essential
B: Stock recommended
C: Less recommended
X: No stock recommended
7. PARTS LIST
FRONT CASE BLOCK
M10E M10R
1 1017 4741 CASE ASSY/FRONT 39-W7911-011 1 1 BR C
2 1017 8340 PANEL/DISPLAY 42-W7911-010 1 1 BQ C
3 1017 4739 PANEL/KEY 40-W7911-020 1 1 BP C
4 1017 4743 KEY/UP&DOWN 42-W7911-050 1 1 AT C
5 1017 4744 HOLDER/UP&DOWN KEY 42-W7911-020 1 1 AC X
6 1017 4746 KEY PAD ASSY 42-W7917-101 1 1 CM A
7 1017 4742 VIBRATOR 25-90000-000 1 1 AU C
MIDDLE CASE BLOCK
M10E M10R
8 1017 4749 CASE/MIDDLE 39-W7913-01A 1 1 BF X
9 1017 4748 FPC/KEYBOARD 43-W7917-014 1 1 BQ C
10 1017 4755 ANTENNA/WLAN 23-742R4-008 1 BW C
11 1017 4750 SHEET/BATTERY REMOVAL 47-W7913-021 1 1 AA X
1017 4752 SHEET/US 47-W7913-041 1 AC
1017 4751 SHEET 47-W7913-011 1 AD
1017 8336 PCB ASSY/MAIN EE 77-W7910-004-2E 1 EY
1017 8333 PCB ASSY/MAIN ME 77-W7910-004-3E 1 FB
14 1017 4754 SCREW/M2*4L 35-C1120-4RA 6 7 AC X
15 1017 4756 SCREW/TAP T2*4L 35-C1120-6R0 2 2 AC X
12 X
13 A
Quantity
Price
Code
R
Item # Part No. Part Name Descriptions
Quantity
Price
Code
R
Item # Part No. Part Name Descriptions
To Next Page
