44
Snapshot Tutorial
1. In the REC mode, press [SET].
2. Use [8] and [2] to select the bottom control panel option (Date/Time).
You can use [4] and [6] to select date or time display.
NOTE
• You can select either of two display styles (page 148) for the date: Month/Day or
Day/Month.
• The time is displayed using 24-hour format.
Your camera provides you with 3X optical zoom (that changes the lens focal
distance), which can be used in combination with digital zoom (that digitally
processes the center portion of the image to enlarge it) for total zoom capabilities of
3X to 47.8X. The image deterioration point depends on the image size (page 45).
1. In the REC mode, slide the zoom controller to zoom.
2. Press the shutter button to shoot the image.
Changing the Control Panel Date/Time Style
Shooting with Zoom
w (Wide Angle): Reduces the size of the subject and broadens the range
z (Telephoto) : Enlarges the subject and narrows the range
w Wide Angle z Telephoto
Zoom controller
To Next Page
