— 1 —
• CPU Name UPD780058BGC124-8BTA
Number of control bit 8 bit
Mask ROM (Built-in) 60 Kbytes
RAM (Built-in) 1024 bytes
• Printer Name M-42V-009-040
Print method Print wheel selecting type serial printer
MCBF 700,000 lines
• Roll paper Type Fine-quality paper
Size Width 57.5 ± 0.5 mm
Roll diameter 80 mm or less
1. SPECIFICATIONS
1-1. Electrical specifications
120 V 220 V 230 V 240 V
• Power consumption In operation Max. 0.1 A 0.05 A 0.05 A 0.05 A
• Memory protection Back-up battery Mangan Battery (UM-3 × 3 pcs)
Back-up period 1 year (25 °C)
Battery life Replace the battery every 1 years.
• Clock & Calendar Accuracy Within ± 30 sec. per month
Auto calendar Effective until 2099 A.D.
1-2. Environmental specifications
• Operating temperature 0 °C ~ 40 °C
• Operating humidity 10 % ~ 90 %
• Storage temperature -25 °C ~ 65 °C
• Storage humidity 10 % ~ 95 %
• Vibration strength 1.5 G (The machine must be in the carton box)
1-3. Main components
1-4. Drawer List
DRAWER NAME Specification NOTE
• DL-1329A (S type) D-21G2M-D54RM-16A U.S.A
• DL-1841A (S type) D-21G2M-D53RM-16A UK/Germany, Europe, Other countries
• DL-2794A (M type) D-18G2C-B84RM-13A Europe, Other countries
• DL-2796A (M type) D-18G2C-A84RM-13A Canada
