— 5 —
4.
DISASSEMBLY
■
Removing the register
1.
Remove the journal cover and then the WINDING PULL
Y and ROLL
P
APER.
5.
Remove the connector (CNDRW1) and then separate the main unit from the drawer
.
2.
Remove the battery cover and then the battery
.
3.
Remove the two screws.
4.
Separate the main unit as shown below
.
Screws
Connector
(CNDRW1)
6
8
