Casio PCR-262 Service Manual

— 30 —
130CR
Price
Code
UK Europe USA
1. MAIN PCB BLOCK & MAIN DISPLAY BLOCK
N 1 1018 5203 PCB ASSY/E264-1 RJE501349*002V01 1 1 1 DD A
N 1 1018 5245 PCB ASSY/E264-1 RJE501349*003V01 1 1 1 1 DG A
N IC3 1019 1510 LSI D780058BGC124-8BTA 1 1 1 1 1 1 1 BI B
IC4 2120 6253 IC LB1268 1 1 1 1 1 1 1 AG C
N IC1 1019 5663 IC BA05CC0T 1 1 1 1 1 1 1 AL C
N IC5,6 2240 5365 IC TD62083AP 2 2 2 2 2 2 2 AL C
X2 1009 4206 CRYSTAL C-002RX-8.3/10 1 1 1 1 1 1 1 AF C
N X1 1019 5676 CRYSTAL/CERAMIC CSTLS5M00G56 1 1 1 1 1 1 1 AC C
N IC2 1019 5674 IC/RESET S-80828CNY-Z 1 1 1 1 1 1 1 AD C
Q3,10 2250 1632 TRANSISTOR DTC114YSA-TP 2 2 2 2 2 2 2 AC C
Q4 2250 1636 TRANSISTOR DTA143ZSA-TP 1 1 1 1 1 1 1 AA C
N Q6-9 1019 5661 TRANSISTOR 2SB1237TU2(QR) 4 4 4 4 4 4 4 AB C
Q1 2250 1036 TRANSISTOR 2SD2396(JK) 1 1 1 1 1 1 1 AE C
Q5 2230 4135 TRANSISTOR 2SD1853-AA 1 1 1 1 1 1 1 AC C
Q2 2250 1628 TRANSISTOR 2SC1740STP(QRS) 1 1 1 1 1 1 1 AA C
DSP1-4 2 1007 2597 HDSP-521G LED/7SEG 4 4 4 4 4 4 4 AN B
D6-9 DIODE 1SS133T-77 4 4 4 4 4 4 4 X
D1-4,11 DIODE 1SR139-400T-32 5 5 5 5 5 5 5 X
D10 DIODE RB721Q-40T-77 1 1 1 1 1 1 1 X
D5 DIODE RB441Q-40T-77 1 1 1 1 1 1 1 X
ZD2 DIODE/ZENER MTZJT-77 4.7A 1 1 1 1 1 1 1 X
ZD1 DIODE/ZENER MTZJT-77 6.8A 1 1 1 1 1 1 1 X
L1 FILTER/LINE CM05RB03 1 1 1 1 1 1 1 X
R25,34-47 RESISTOR/CHIP CFS1/4CT26A101J 15 15 15 15 15 15 15 X
R14,101-117 RESISTOR/CHIP CFS1/4CT26A151J 18 18 18 18 18 18 18 X
R62,64,66,68 RESISTOR/CHIP CFS1/4CT26A511J 4 4 4 4 4 4 4 X
R13 RESISTOR/CHIP CFS1/4CT26A561J 1 1 1 1 1 1 1 X
R19,20,61,63,65,67,74-76 RESISTOR/CHIP CFS1/4CT26A102J 9 9 9 9 9 9 9 X
R2,3,6,7,10,12 RESISTOR/CHIP CFS1/4CT26A103J 6 6 6 6 6 6 6 X
R4,5,8,9,15-18,21-24,
R27-33,48,49,53-59,69,70
R26,71-73 RESISTOR/CHIP CFS1/4CT26A104J 4 4 4 4 4 4 4 X
R50 RESISTOR/CHIP CFS1/4CT26A334J 1 1 1 1 1 1 1 X
R52 RESISTOR/CHIP CFS1/4CT26A155J 1 1 1 1 1 1 1 X
R1 RESISTOR/METAL OXIDE MOS1/2CL10A681J 1 1 1 1 1 1 1 X
R51 RESISTOR/METAL OXIDE MOSX1CL12.5A1R2J 1 1 1 1 1 1 1 X
R60 RESISTOR/METAL OXIDE MOS1CT52A100J 1 1 1 1 1 1 1 X
C19 CAPACITOR/CHIP RT-HE40TKCH120J 1 1 1 1 1 1 1 X
C20 CAPACITOR/CHIP RT-HE40TKCH150J 1 1 1 1 1 1 1 X
C6,21 CAPACITOR/CHIP RT-HE40TKYB221K 2 2 2 2 2 2 2 X
C9,27-29 CAPACITOR/CHIP RT-HE60TKYB222K 4 4 4 4 4 4 4 X
C18,22-25 CAPACITOR/CHIP RT-DSTC50TKYR103K 5 5 5 5 5 5 5 X
C1 CAPACITOR/CHIP RT-HE12TKYB103K 1 1 1 1 1 1 1 X
C3,7 CAPACITOR/CHIP UVR1A101MDD1TA 2 2 2 2 2 2 2 X
C4 CAPACITOR/CHIP UVR1E331MPD1TD 1 1 1 1 1 1 1 X
C5,8,26 CAPACITOR/CHIP QYX1H103KTP1FD 3 3 3 3 3 3 3 X
C2 CAPACITOR/CHIP UVR1E472MHD 1 1 1 1 1 1 1 X
N CNBAT1 1019 5662 CONNECTOR 5267-02A-X 1 1 1 1 1 1 1 AA C
Item
Other Countries
Plug Type
RESISTOR/CHIP CFS1/4CT26A563J 30 30
N RankSpecificationParts NameCode No.
Q'ty
Europe UK AustraliaGermany
30 X30 30 30 30
