CDA WC461 User Manual

17
Installation
• Do not install this appliance if it is damaged in any way. Installing a
damaged appliance may invalidate the warranty.
• The water supply tap should be located in an adjacent cupboard so that it
can be accessed after installation.
• Ensure the appliance is level by adjusting the feet as necessary. The
dishwasher is equipped with an adjustable rear foot that can be raised or
lowered by means of an adjustment screw, located in the centre of the
kick plate.
• Only use the water inlet supplied with the appliance.
• If the water pressure is above 10 bar, a pressure relief valve should
be used.
• After connecting the water supply, check to ensure there are no leaks.
• The water outlet can either be connected to a water drain or to a sink
outlet spigot. This connection should be at a minimum of 50 cm and a
maximum of 110 cm from the floor. The drain hose should be no longer
than 4m in length to ensure good performance from the dishwasher.
• To prevent siphoning, ensure that the water outlet is not pushed too far
into the waste standpipe. The lowest part of the water outlet should be
level with the bottom basket of the dishwasher.
• When connecting to the sink, ensure that the waste pipe runs higher
than the level of the sink bowl to prevent siphoning.
fig. 22
fig. 20
fig. 21

CDA WC461 Specifications

General

Door color	Not applicable
Built-in display	No
Appliance placement	Fully built-in
Control panel color	Black, Stainless steel
Noise level	47 dB
Delay start (max)	19 h
Delayed start timer	Yes
Dishwashing programs	Auto 60-70°C, Glass/delicate, Eco, Intensive, Normal, Pre-wash, Quick
Number of place settings	10 place settings
Number of washing programs	8
Drying class	A
Annual water consumption	3360 L
Annual energy consumption	237 kWh
Water consumption per cycle	12 L
Energy consumption per cycle	0.83 kWh

Weight and Dimensions

Depth	570 mm
Width	448 mm
Height	870 mm
