8. Initial Set-Up
09
The charging time is approx. 4 hours.
The battery is full when the blue L.E.D,
the charging symbol goes out at the
battery, and the green L.E.D. on the
charging cable lights up.
Press the «Power» button above the
keyboard. The «Power» L.E.D. Lights
up immediately.
After approx. 15 seconds the device is
ready for operation and the «Ready»
LED lights up. The blue LED
and
the green P1 LED light
up.
Remove the KLOUD
devices
from the design box and place them
on a at surface.
Before using the applicator for the
rst time, charge the batteries. To
do this, connect the power supply
unit to the respective applicator with
the USB cable (see chapter Batte-
ry). Make sure that you rst click the
power plug that corresponds to the
power supply in your country into
the adapter. You can use the other
adapter in other countries, e.g. when
travelling.
The power supply unit and plug must
be in undamaged original condition.
Contact CENTROPIX for replacement
of damaged parts immediately!
Info: When removing the magnetic
charging cable, the dongle can come
o. Disconnect the dongle from the
charging cable and plug it back into
the socket.
1 2 3
9. Control Unit
10
Program selection
button
Program & intensity display
Custom program: additionally
selectable via the app
Blue LED lights up:
Device is switched on
Green LED lights up:
Device is ready for
operation
When charging:
Blue LEDs on (device & charging cable) = battery is charging
Blue LED on device is o and green LED on charging cable is on =
battery fully charged
Red LED lights up or ashes:
Battery almost empty
App connection
button
Program Start / Stop
button
TIP:
How to use the LEDs and
the deactivate sound signals
can be found under the menu
item «application».
Blue LED is on:
Connected via Bluetooth
On and o button
Connection for charging
cable (magnetic)
Ventilation slots
DE ENFRPL ES
