DE ENFRPL ES
29
17. Specications
Category
KLOUD
maxi KLOUD
mini
Item No. 1128 1129
Measurement (LxW) 164 x 67 cm (64.57” x 26.38”) 98 x 43 cm (38.58” x 16.93”)
Weight 2,2 kg (4.85 lb) 0,99 kg (2.18 lb)
Serial No.
Fold up the KLOUD . There is a leather ap on the side of the head section that leads to the battery compartment.
Open this leather ap and fold down the lower ap underneath. There you will nd the serial number of the KLOUD .
You can also nd the serial number on the last page of this User Manual.
Operating voltage 12-15, 1VDC
Surface material *)
• Upholstery material
• Features
• Fire protection standard
Front side 100% polyester, back side: 100% PVC
PES, Flexathen FT/SPE 33 FR, polyethylene foam
Flame retardant, stain resistant
FMVSS 302 / ISO 75200 / BS 5852 Source 1, EN 1021-1&2
Power consumption 250 - 650 mAh
(when charging the battery at up to 1,7A)
Coils 8
Power consumption Max. 8,5 W
Power output (on the applicator) Max. 6 W
Maximum ux density of the
application
Mat laid out: ca. 100 μT
3 x folded to: ca. 200 μT
Connections Magnetic charging socket
*) The surface material can change depending on the batch, but this does not aect the high quality level. The colors of the fabrics can also vary slightly.
30
Category SCAN-X
Item number 1130
Weight 60 g (2.12 oz)
Measurement approx.
70 x 40 x 13 mm
(2.76” x 1.58” x 0.5”)
Operating voltage 3 Volt
Power supply Button cell CR 2032
Measuring range 10 Hz - 1 KHz
Signal Sound
Category CHARGER
Item number 1131
Measurement 75 x 40 x 30 mm
(3.0” x 1.6” x 1.2”)
Weight 140 g (incl. cabel) (4.94 oz)
Model FOX12 USB
Adapter EU (10 g) / US (0.35 oz)
Input 100-240 VAC ~
50/60 Hz/300-150mA
Output 5 VAC - 2.2 A
Part-No. 5317-FW8000/USB
Spec.-No. 15.240VAC
Use Indoor only
Material PC / ABS V0
125° C / 257 F°
Category USB-KABEL
Item number 1116
USB type USB Typ A plug
USB 3.1 Typ C plug
Magnetic connector &
dongle
Jacket Material Soft - PVC
Length
180 cm (70.87”)
Category
CLEANING GLOVE
Measurement (LxW) approx. 21 x 14 cm
(8.3” x 5.5”)
Weight 80 g (2.82 oz)
Material 60 % Polyamide
40 % Cotton
Category AKKU
Capacity 4000 mAh
Minimum capacity 3900 mAh
Nominal voltage 3,6 V - 3,7 V
Final charge voltage 4,2V ± 0,05
Final discharge
voltage
2,5 V
Max. discharge
current (constant)
45A
with switch-o
at 80° C / 176 F°
Max. discharge
current (constant)
35A
without shutdown
Max. discharge
current (pulse)
approx. 70 A
Diameter 21,15 mm ± 0,15 mm
(0.8327”± 0.0059”)
Height 70,15 mm ± 0,2 mm
(2.7618” ± 0.0079”)
Weight 70 g ± 1 g
(2.47 oz ± 0.04 oz)
Charging procedure CC-CV
