chapter 6000
page 16
1,2 - 2,0 t A.C.
SERVICE MANUAL
Electric
036-0410-07
Tightening torque 45 +/- 5 Nm
clean carefully the motor coupling surface
insert the shaft in the tootded seating
Before insert the motor shaft be sure that in the toothed seating
there is a thin layer of "CASTROL OPTIMOL T. WHITE" (paste
or spray). If not, restore the layer with the product before
mentioned.
screw in and tight the two bolts
After the pump replacement it is suggested to fill the suction hose C (see previous page). It is also
possible to use the manometer connection point D (see previous page) to fill the main hose C with oil in order
to avoid that the pump turns without oil during the first working period. Once ending the assembling operation
switchthe truck on and wait for the lifting motor automatic stop.
D
