chapter 6000
page 15
1,2 - 2,0 t A.C.
SERVICE MANUAL
Electric
036-0410-07
A
B
D
C
A
B
D
C
To change oil and filter:
The tank does not have the drain plug. Place and stop the
truck on a flat surface, with the mast tilted backwards and
the forks lowered. Two different procedures can be
followed to replace the hydraulic oil:
1) To drain the tank it is possible to use a pump to such
up the hydraulic oil
2) It is also possible to remove the drain hose of the
control valve from the tank and place it on an
external case. By pressing the brake pedal
(at the minimum RPM of the lifting pump) the oil
flows out. When the tank is nearly empty switch the
the truck off by the key
Be careful! The pump must not work without oil.
Before fitting the new pump to the motor pay attention to the gasket right
positioning.
PUMP REPLACEMENT
