Headlamp Aiming
The vehicle has a visual optical headlamp aiming
system. The aim of the headlamps have been
preset at the factory and should need no further
adjustment.
However, if the vehicle is damaged in an accident,
the aim of the headlamps may be affected and
adjustment may be necessary.
If oncoming vehicles flash their high beams at
you, this may mean the vertical aim of your
headlamps needs to be adjusted.
It is recommended that the vehicle is taken to your
dealer for service if the headlamps need to be
adjusted. It is possible however, to re-aim
the headlamps as described in the following
procedure.
The vehicle should be properly prepared as
follows:
• The vehicle should be placed so the
headlamps are 25 ft. (7.6 m) from a light
colored wall or other flat surface.
• The vehicle must have all four tires on a level
surface which is level all the way to the wall
or other flat surface.
• The vehicle should be placed so it is
perpendicular to the wall or other flat surface.
• The vehicle should not have any snow, ice, or
mud on it.
• The vehicle should be fully assembled and all
other work stopped while headlamp aiming is
being performed.
