A-1
Cisco Secure Router 520 Series Hardware Installation Guide
OL-12892-01
APPENDIX
A
Specifications
This appendix provides system, port, and cabling specifications for the Cisco Secure Router 520 Series
routers. It contains the following sections:
• Router Specifications, page A-1
• LAN Port Pinouts, page A-2
• Console Connector Pinouts, page A-3
• ADSL Port Connector Pinouts, page A-3
• Cable Specifications, page A-4
Router Specifications
Table A-1 provides the system specifications for the routers.
Ta b l e A-1 Router Specifications
Description Design Specification
Physical Dimensions
Dimensions (W x D x H) • With antenna connectors: 10.578 in. (268.68 mm) x
8.65 in. (219.72 mm) x 1.719 in. (43.66 mm)
• Without antenna connectors: 10.578 in. (268.68 mm)
x 8.289 in. (210.54 mm) x 1.719 in. (43.66 mm)
Weight (not including desktop power supply) 3.7 lb
Environmental Operating Ranges
Nonoperating temperature –4 to 149°F (–20 to 65°C)
Nonoperating humidity 5 to 95% relative humidity
Nonoperating altitude 0 to 15,000 ft (4570 m)
Operating temperature 32 to 104°F (0 to 40°C)
Operating humidity 10 to 85% relative humidity
Operating altitude 0 to 10,000 ft (3000 m)
Router Power
AC input voltage 100 to 240 VAC
