Cisco 7942G Administration Guide

7-9
Cisco Unified IP Phone 7962G and 7942G Administration Guide for Cisco Unified Communications Manager 6.1(3)
OL-17679-01
Chapter 7 Viewing Model Information, Status, and Statistics on the Cisco Unified IP Phone
Status Menu
Firmware Versions Screen
The Firmware Versions screen displays information about the firmware version that is running on the
phone.
Table 7-4 describes the information that is displayed on this screen.
To display the Firmware Version screen, follow these steps:
Procedure
Step 1 Press the Settings button.
Step 2 Select Status.
Step 3 Select Firmware Versions.
To exit the Firmware Version screen, press the Exit softkey.
One of the following values:
Initialized
TCP-timeout
CM-closed-TCP
TCP-Bad-ACK
CM-reset-TCP
CM-aborted-TCP
CM-NAKed
KeepaliveTO
Failback
Phone-Keypad
Phone-Re-IP
Reset-Reset
Reset-Restart
Phone-Reg-Rej
Load Rejected HC
CM-ICMP-Unreach
Phone-Abort
Cause of the last reset of the phone
Elapsed Time Amount of time that has elapsed since the phone last rebooted
Port 1 Link state and connection of the PC port (for example, Auto
100 Mb Full-Duplex
means that the PC port is in a link-up
state and has auto-negotiated a full-duplex, 100-Mbps
connection)
Port 2 Link state and connection of the Network port
DHCP BOUND Phone is bound to the DHCP server, DHCP parameters are
acceptable, and the phone has received a DHCPACK message.
Table 7-3 Network Statistics Message Information (continued)
Item Description
