4-5
Cisco Unified IP Phone 7962G and 7942G Administration Guide for Cisco Unified Communications Manager 6.1(3)
OL-17679-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Network Configuration Menu
Related Topics
• Displaying a Configuration Menu, page 4-2
• Unlocking and Locking Options, page 4-3
• Editing Values, page 4-3
• Network Configuration Menu, page 4-5
• Device Configuration Menu, page 4-11
Network Configuration Menu
The Network Configuration menu provides options for viewing and making a variety of network settings.
Table 4-2 describes these options and, where applicable, explains how to change them.
For information about how to access the Network Configuration menu, see the “Displaying a
Configuration Menu” section on page 4-2.
Note The phone also has a Network Configuration menu that you access directly from the Settings menu. For
information about the options on that menu, see the
“Network Configuration Menu” section on
page 4-24.
Before you can change an option on this menu, you must unlock options as described in the “Unlocking
and Locking Options” section on page 4-3. The Edit, Ye s , or No softkeys for changing network
configuration options appear only if options are unlocked.
For information about the keys you can use to edit options, see the “Editing Values” section on page 4-3.
TFTP settings If you do not use DHCP to direct the phone to a TFTP
server, you must manually assign a TFTP server. You can
also assign an alternative TFTP server to use instead of the
one assigned by DHCP.
TFTP Server 1
Alternate TFTP
TFTP Server 2
Table 4-1 Settings Configurable from the Phone (continued)
Category Description Network Configuration Menu Option
Ta b l e 4-2 Network Configuration Menu Options
Option Description To Change
IPv4 Configuration In the IPv4 Configuration menu, you can do the
following:
• Enable or disable the phone to use the IP address
that is assign by the DHCP server.
• Manually set the IP Address, Subnet Mask,
Default Routers, DNS Server, and Alternate TFTP
servers.
For more information on the IPv4 address fields, refer
to
Table 4-4.
1. Unlock network configuration options.
2. Scroll to IPv4 Configuration and press
the Select softkey.
MAC Address Unique Media Access Control (MAC) address of the
phone.
Display only—Cannot configure.
