Cisco 8845 Administration Guide

Step 5 Press the phone firmly into the wall bracket and slide the phone down. The tabs in the bracket click into
position.
Step 6 Proceed to Adjust the Handset Rest, on page 136.
Remove the Phone from the Non-Lockable Wall Mount
The wall bracket has two tabs that lock the kit together. Use the following illustration to locate the tabs.
Figure 14: Tab Location
Before you begin
Obtain two Phillips head screwdrivers or other similar devices that have a diameter of 5 millimeters or 3/16ths
of an inch.
Procedure
Step 1 Insert a screw driver or other device into the left and right holes in the phone mounting plate. Insert to a depth
of about 3/4 of an inch or 2 centimeters.
Step 2 Press firmly inwards to disengage the tabs.
Cisco IP Phone 8800 Series Multiplatform Phones Administration Guide
129
Hardware and Accessory Installation
Remove the Phone from the Non-Lockable Wall Mount
