You can use a CFP2 adapter to connect the CPAK transceivers to the MPA. The router only detects a connected
CPAK transceiver module and does not detect the physically intermediate CFP2 adapter. The show inventory
command shows the connected CPAK transceiver module.
This table lists the CFP2 adapters and the supported CPAK modules:
Supported CPAK transceiver moduleCFP2 Adaptor
CPAK-100G-LR4
CPAK-100G-ER4L
CPAK-100G-CWDM4
CVR-CFP2-CPAK4
CPAK-100G-SR10
CPAK-10X10G-LR
CPAK-10X10G-ERL
CVR-CFP2-CPAK10
Plugging a non-supported CPAK to a CFP2 adapter can damage the CFP2 adapter. Ensure that you read the
PID label on the CFP2 adapter carefully.
Caution
It is strongly recommended to wait for 60 seconds before successive insertion or removal of optics. Failure
in following this recommendation may affect the functionality of optics.
Caution
The metal surfaces of CPF2-DCO modules may exhibit high temperature and can be unsafe for handling with
bare hands.
Caution
For more information about how to remove the CFP2-DCO module, see Safe Removal of CFP2-DCO Modules,
on page 87.
1-Port 200-Gigabit Ethernet Modular Port Adapter with CFP2-DCO
The 1-Port 200-Gigabit Ethernet (GE) modular port adapter (MPA) supports OTN mode and provides a single
cage of coherent transceiver CFP2-DCO module that operate at a rate of 100 Gbps or 200Gbps. The 1-Port
200GE MPA is supported in both bay 0 and bay 1 of 400 Gigabit Modular Line Card (A9K-MOD400-SE,
A9K-MOD400-TR) and only on Bay 0 of 200 Gigabit Modular Line Card (A9K-MOD200-SE,
A9K-MOD200-TR).
• V02 version of the CFP2-DCO module is introduced. V02 version of the optical module supports Staircase
FEC. Staircase FEC is an industry standard that enables high-speed optical communications. Version ID
information of the optical module can be obtained from the show inventory command output.
• This MPA does not support any breakout configuration.
Note
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
48
Overview
1-Port 200-Gigabit Ethernet Modular Port Adapter with CFP2-DCO
