Cisco Aironet Series Power Injectors AIR-PWRINJ-60RGD1= and AIR-PWRINJ-60RGD2= Installation Instructions
AIR-PWRINJ-60RGDx= Technical Specifications
AIR-PWRINJ-60RGDx= Technical Specifications
Input voltage 90 to 264 VAC
Output voltage 55 VDC ± 2%
Maximum current 2.0 A
Operating temperature
-40º to 122ºF (-40 to 50ºC) for 60W
-40º to 131ºF (-40 to 55ºC) for 30W
Storage temperature –40º to 185ºF (–40º to 85ºC)
Operating humidity Maximum 95%, Non-condensing
Storage humidity Maximum 95%, Non-condensing
Thermal Rating 45 BTU/Hr (@264VAC)
Weather Rating IP66, NEMA 4X
Length 8.42 in. (214 mm)
Width 5.90 in. (150 mm)
Height 2.75 in (70 mm)
Weight 2.98 lbs (1.35Kg)
AC Power Cable
Length
3.03 meters
Regulatory and Safety Compliance
Regulatory
Compliance
IEEE 802.3af, IEEE 802.3at, RoHS Compliant,
WEEE Compliant, CE
Electromagnetic
Emission & Immunity
FCC Part 15, Class B
CE, EN50522 Class B, EN55024
VCCI
EN61000-4-5 Class 5 (6kV CM)
Safety Approvals
UL60950-1 & UL60950-22
GS Mark
Surge Protection
Meets Surge Protection as specified in
GR-1089-CORE Issue 4
ITU-T K.20 6 kV on AC lines
