Cisco ASR 1002 Replacing

Removing and Replacing the Cisco ASR 1000 Series DIMM
Memory Modules
Cisco ASR 1000 Series Routers support the Cisco ASR1000-RP1 and the Cisco ASR1000-RP2 route processor
DIMM memory modules for system DRAM. This section describes how to replace the DIMMs on the Cisco
ASR1000-RP1, the Cisco ASR1000-RP2 route processors, the Cisco ASR 1001, and the Cisco ASR 1002-X
routers.
The following table shows the Cisco ASR1000-RP1 and Cisco ASR1000-RP2 memory design.
Table 1: Cisco ASR 1000 Series Route Processor Memory Support
Cisco ASR1000-RP2Cisco ASR1000-RP1
Supports up to 16 GB memorySupports up to 4 GB memory
• 4 GB dual rank VLP DIMMs• 1 GB (2 GB)
miniDIMMs
• Up to 4 DIMMs with up to two DIMMs per
channel
• DDR-533
• Allowable memory options of 4 GB, 8 GB, or 16
GB
—
• DDR-667—
You might need to upgrade the DIMM for the following reasons:
• You have upgraded to a new Cisco IOS feature set or release that requires more memory.
• You are using very large routing tables or many protocols.
This section contains the following topics:
Removing and Replacing the DIMM Memory Modules on the Cisco ASR 1006
Router and the Cisco ASR 1013 Router
The Cisco ASR 1006 Router and the Cisco ASR 1013 Router have redundant RPs. The following is an
overview of the steps to remove and replace the DIMM memory modules on these routers:
SUMMARY STEPS
1. Remove the standby RP by performing the procedure described in the xref “Removing the Cisco ASR
1000 Series Route Processor from the Cisco ASR 1006, Cisco ASR 1004, and Cisco ASR 1013 Routers”
section.
2. Remove the DIMM memory module from the standby RP by performing one of the following procedures:
• Removing and Replacing the Cisco ASR1000-RP1 DIMM Memory Modules
Removing the Cisco ASR1000-RP2 DIMMs
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
19
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing the Cisco ASR 1000 Series DIMM Memory Modules

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
