Requirement
Management Action to
Log
Sample Log
[Source: 21.0.0.3] [localport: 22] at 00:05:49 EST
Thu Jan 17 2013
FIA_UAU_EXT.2:
Password-based
authentication mechanism
None
N/A
FIA_UAU.7: Protected
authentication feedback
None
N/A
FIA_X509_EXT.1: X.509
Certificate Validation
Generating a certificate.
Feb 17 2013 16:14:47: %PARSER-5-
CFGLOG_LOGGEDCMD: User:test_admin
logged command: crypto key generate
FMT_MOF.1: Management
of Security Functions
Behavior
See all other rows in table.
N/A
FMT_MTD.1: Management
of TSF data
See all other rows in table.
N/A
FMT_SMF.1: Specification
of management functions
See all other rows in table.
N/A
FMT_SMR.2: Restrictions
on Security roles
Configuring administrative
users with specified roles.
Feb 15 2013 13:12:25.055: %PARSER-5-
CFGLOG_LOGGEDCMD: User:cisco logged
command: username admin 15
FPT_RUL_EXT.1: Packet
Filtering
Configuring packet
filtering rules.
Oct 15 23:39:50 cc_toe 21698: Oct 15
23:39:50.077: \%PARSER-5-
CFGLOG_LOGGEDCMD: User:script logged
command:permit icmp 10.32.0.203 0.0.0.0
10.31.0.101 0.0.0.0 log
Oct 15 23:39:50 cc_toe 21700: Oct 15
23:39:50.261: \%PARSER-5-
CFGLOG_LOGGEDCMD: User:script logged
command:deny icmp 10.32.0.203 0.0.0.0
10.31.0.101 0.0.0.0 log

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
