Removing RSP Cards and Line Cards from the Cisco ASR 9006, 9010, 9904, 9906, and 9910 Routers
This section describes how to remove RSP and line cards from the Cisco ASR 9006 Router, Cisco ASR 9010
Router, Cisco ASR 9904 Router, Cisco ASR 9906 Router, and Cisco ASR 9910 Router. The below table and
Table 2: Router Components and Slot Numbering for the Cisco ASR 9922 Router and Cisco ASR 9912 Router,
on page 38) and describe the router components and slot numbering for each router.
Table 1: Router Components and Slot Numbering for the Cisco ASR 9006 Router, Cisco ASR 9010 Router, Cisco ASR 9904 Router, Cisco ASR 9906 Router, and Cisco
ASR 9910 Router
Router Components and Slot NumberingRouter Model Number
• 6 slots.
• Version 1 power system (Figure 20: Cisco ASR 9006 Router Components and Slot Numbering with
Version 1 Power System, on page 28) or Version 2 power system (Figure 21: Cisco ASR 9006
Router Components and Slot Numbering with Version 2 DC Power System, on page 29).
• Two RSP cards installed in the two lowest slots (labeled RSP0 and RSP1) located above the power
modules.
• Four line cards installed in slots 2 through 5 above the RSP card slots.
Cisco ASR 9006 Router
• 10 slots.
• Version 1 power system (Figure 22: Cisco ASR 9010 Router Components and Slot Numbering with
Version 1 Power System or Version 3 AC Power System, on page 29), Version 2 power system
(Figure 23: Cisco ASR 9010 Router Components and Slot Numbering with Version 2 Power System
or Version 3 DC Power System, on page 30), or Version 3 power system ( Figure 22: Cisco ASR
9010 Router Components and Slot Numbering with Version 1 Power System or Version 3 AC Power
System, on page 29 for AC and Figure 23: Cisco ASR 9010 Router Components and Slot Numbering
with Version 2 Power System or Version 3 DC Power System, on page 30 for DC).
• Two RSP cards installed in the two center slots (labeled RSP0 and RSP1).
• Four line cards installed in slots 0 through 3 to the left of the RSP card slots.
• Four line cards installed in slots 4 though 7 to the right of the RSP card slots.
Cisco ASR 9010 Router
• 4 slots.
• Version 2 power system (Figure 24: Cisco ASR 9904 Router Components and Slot Numbering with
Version 2 DC Power System , on page 30).
• One line card installed in the top slot (labeled LC1). Two RSP cards installed in the middle two slots
(labeled RSP1 and RSP0) located between the line cards (LC0 and LC1).
• One line card installed in the lowest slot (LC0) located above the power modules.
Cisco ASR 9904 Router
Unpacking and Installing the Chassis
27
Unpacking and Installing the Chassis
Removing RSP Cards and Line Cards from the Cisco ASR 9006, 9010, 9904, 9906, and 9910 Routers
