Control SourceDescriptionColorLED
Bezel sideSingle LTE modem (one
modem with SIM
switch-over capability)
Off: Modem not up or
modem up and no SIM
Amber steady on:
Modem up, SIM installed
but not active.
Green Blink: LTE data
activity.
Green and AmberLTE DATA/SIM
(C1101-4PLTEPWz
C1101-4PLTEP/C1101-4PLTEPWx)
I/OWLAN functions3-color LED: Green, Red
and Amber;
WLAN
(C1101-4PLTEPWx)
I/OUSB console status
OFF: USB console not
active
ON: USB console active
GreenUSB console
I/OUSB 3.0 status
OFF: No USB device
discovered
ON: USB device
discovered
USB activity
GreenUSB 3.0
Reset Button
The actuation of the Reset button is only recognized during ROMmon boot, that is, as the router comes to the
ROMmon prompt.
The Reset button does not require much force to be pressed. The Reset button should be pressed only with a
small implement such as the tip of a pen or a paper clip. When the Reset button is pressed at startup, the system
LED turns green.
For more information, see the "Reset Overview" section of the Cisco 1100 Software Configuration Guide.
Power Supply
• AC input voltage: Universal 100 to 240 VAC
• Frequency: 50 to 60 Hz
• Maximum output power: Up to 66W for non-PoE supply and upto 150W for PoE supply
• Optional PoE and PoE+
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
20
Overview of Cisco 1000 Series Integrated Services Routers
Reset Button

Cisco C1111x-8P Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Frequency range	2.4 - 5 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB version	3.2 Gen 1 (3.1 Gen 1)
Ethernet LAN (RJ-45) ports	8
Installed SFP modules quantity	4
Fast Ethernet (copper) ports quantity	1
Power over Ethernet (PoE) ports quantity	6
Security algorithms	3DES, 128-bit AES, 256-bit AES, DES
Authentication method	RSA (748/1024/2048 bit), ECDSA (256/384 bit); Integrity: MD5, SHA, SHA-256, SHA-384, SHA512
Routing protocols	VRRP
Data link protocols	HDLC
Supported protocols	IPv4, IPv6, RIP, RIPv2, OSPF, EIGRP, BGP, IS-IS, IGMPv3, PIM SM, SSM, RSVP, ERSPAN, IPSLA, EEM, IKE, ACL, EVC, DHCP, FR, DNS, LISP, HSRP, RADIUS, AAA, AVC, DVMRP, MPLS, IPsec, L2TPv3, BFD
Switching protocols	RFC 2338
IPv4 & IPv6 features	Dual stack IPv4/IPv6
Supported network protocols	ACL, NAT, QoS, BFD, VRF Lite, IP SLA
Antenna type	External
Antennas quantity	2
Product color	Gray
LED indicators	Link, Status
Country of origin	Czech Republic
Flash memory	4000 MB
Certification	UL 60950-1.and EN 60950-1. CAN/CSA C22.2 No. 60950-1. CB to IEC 60950-1, 2
Internal memory type	DRAM
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC, PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	66 W
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-4 - 149 °C
Operating temperature (T-T)	32 - 104 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Package type	Box
Package depth	508 mm
Package width	342.9 mm
Package height	162.052 mm
Package weight	3455.78 g
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	244 mm
Width	323 mm
Height	44 mm
Weight	1940 g
