Figure 17: Bottom of the Router with Rubber Feet
1. Rubber Feet (1 of 4)
Do not stack up routers.
Note
Mount the Router under a Desk or a Shelf
Installing the router under a desk requires an optional bracket kit that is not included with the router. The kit
contains the rack-mount brackets and screws to secure the brackets to the router and the underside of the desk.
You can order these kits from your Cisco representative. This procedure describes how to mount router under
a desk or a shelf .
Step 1 Attach a bracket to one side of the router using the flat-head screws (Refer Figure 19: Flat-head Machine Screws, on page
26). Follow the same steps to attach the second bracket to the opposite side.
Hardware Installation Guide for the Cisco 900 Series Integrated Services Router
25
Install and Connect the Router
Mount the Router under a Desk or a Shelf
