Status LED
The status LED indicates the status of the system.
Table 7: Status LED Indicator
DescriptionColor/State
System is not operational.Off
System is operating normally without alarms.Green
System has triggered a minor environmental alarm.Amber
System has triggered a major environmental alarm.Red
System ID LED
The System ID (blue beacon) LED can be provisioned by the operator to indicate that the switch needs
attention.
Table 8: System ID LED Indicator
DescriptionColor/State
The system needs attention.Blinking blue
Management Port LED
This table describes the management port LEDs.
Table 9: Management Port LED Indicator
DescriptionColor/State
Port is not provisioned.Off
Port is provisioned, but administratively not operational.Amber
Port is linked up.Green
A port fault is detected, or the port beacon has been provisioned by
the operator.
Alternating green and amber
Fan Tray LED
The Fan LED is located on the front panel of the switch. The following image depicts the Fan LED, the system
status LED, and the blue beacon LED on the front panel of the switch.
Catalyst 6840-X Switch Series Hardware Installation Guide
17
Product Overview
Status LED
