• No parity
• None (flow control)
Step 5 Power on the switch as described in the switch getting started guide.
Step 6 The PC or terminal displays the bootloader sequence. Press Enter to display the setup prompt. Follow the
steps in the Setup program.
IP Settings
To set up the switch, you need to assign an IP address and other configuration information necessary for the
switch to communicate with the local routers and the Internet.
You will need this information from your network administrator:
• Switch IP address
• Subnet mask (IP netmask)
• Default gateway (router)
• TFTP Server
Performing the Initial Configuration
The bootup script runs the configuration wizard, which prompts you for basic configuration input. At any
point you may enter a question mark '?' for help. Use Ctrl+C to abort the configuration dialog at any prompt.
Default settings are in square brackets '[ ]'.
Procedure
Step 1 Respond to whether you would like to enter the initial configuration dialog
Example:
Would you like to enter the initial configuration dialog? [yes/no]: yes
Step 2 Repond to whether you would like to enter basic management setup
Example:
Would you like to enter basic management setup? [yes/no]: yes
Step 3 Repond to whether you would like to enter basic management setup
Example:
Would you like to enter basic management setup? [yes/no]: yes
Configuring global parameters:
Enter host name [Switch]: Switch
The enable secret is a password used to protect access to
privileged EXEC and configuration modes. This password, after
entered, becomes encrypted in the configuration.
Enter enable secret: examplesecret
