DescriptionFeature
The switch supports a single front and rear serviceable
and hot-swappable fan tray with 12 fans.
Supported model number (add = for
spare)—C9407-FAN
See Fan Tray Assembly Overview, on page 16 and
Fan Tray LEDs, on page 161
Fan tray assembly
The chassis supports up to four field-replaceable
AC-input and DC-input power supply modules.
Supported model numbers (add = for spare):
• C9400-PWR-2100AC
• C9400-PWR-3200AC
• C9400-PWR-3200DC
See Power Supply Module Overview, on page 19 and
Power Supply LEDs, on page 162
Power supplies
120 Gbps backplane bandwidth for each payload
module slot with the C9400-SUP-1XL or the
C9400-SUP-1XL-Y Supervisor modules. With the
C9400-SUP-1 Supervisor module, the backplane
bandwidth is 80Gbps.
Each line card slot supports up to 32 channels
connected to each supervisor module slot.
Backplane
The chassis has a built-in, front-facing, passive RFID
tag that uses Ultra High Frequency (UHF) RFID
technology and requires an RFID reader with
compatible software. It provides auto-identification
capabilities for asset management and tracking. The
RFID tags are compatible with the Generation 2 GS1
EPC Global Standard and are ISO 18000-6C
compliant. They operate in the 860-MHz to 960-MHz
UHF band. For more information, see Radio
Frequency Identification (RFID on Cisco Catalyst
9000 Family Switches).
RFID Tag
Catalyst 9410R Switch
The Catalyst 9410R Switch is a ten-slot modular chassis, with two redundant supervisor module slots, eight
switching module slots with up to 384 1-Gigabit Ethernet front panel ports, one non-redundant fan tray
assembly, and a provision to accommodate up to eight power supply modules.
Front View of the Catalyst 9410R Switch
The figure shows a front view of the chassis, with the major components identified:
Cisco Catalyst 9400 Series Switches Hardware Installation Guide
12
Product Overview
Catalyst 9410R Switch
