CHAPTER 3
Switch Mounting
• Switch Mounting, on page 23
Switch Mounting
This chapter describes how to mount the switch.
Mounting the Switch
To prevent the switch from overheating, ensure these minimum clearances:– Top and bottom: 2.0 in. (50.8
mm)– Exposed side (not connected to the module): 2.0 in. (50.8 mm) – Front: 2.0 in. (50.8 mm)
Caution
Installing the Switch on the Wall
To attach the switch to a wall or a panel, follow these steps.
Read the wall-mounting instructions carefully before beginning installation. Failure to use the correct hardware
or to follow the correct procedures could result in a hazardous situation to people and damage to the system.
Statement 378
Warning
Procedure
Step 1 Position the switch mounting bracket against the wall or a panel in the desired location, with the arrow pointing
up. See the following figure. Attach the bracket to the wall with the 4 enclosed Philips screws.
Cisco Catalyst IE3400 Heavy Duty Series Hardware Installation Guide
23
