CHAPTER 6
5G Sub-6 GHz Pluggable Interface Module
This chapter contains the following sections:
• 5G Sub-6 GHz Support on IoT Routing, on page 49
• 5G Pluggable Interface Module Overview, on page 50
• LED Behaviors, on page 51
• RF Band and Port Mapping for the P-5GS6-GL Antenna, on page 52
• Thermal Mitigation, on page 53
• Attaching an Antenna, on page 55
5G Sub-6 GHz Support on IoT Routing
The 5G Sub-6 GHz Pluggable Interface Module offers 5G capability to the IoT Industrial Router family. The
product ID for the pluggable module is P-5GS6-GL. The P-5GS6-GL uses the FN980 Telit modem.
IOS XE release 17.7.1 is the first software release to provide support for the P-5GS6-GL.
Note
Features and Limitations
The following features and limitations apply across all IoT routing platforms unless specifically mentioned:
• IoT routing platforms support a maximum of two pluggable modules, with a combination of 5G and 4G
PIMs.
• The pluggable module can be started or stopped through the CLI under exec mode. Also, it can be
configured to power off the module to reduce power consumption as needed.
• The capability to disable FDD Band 30 for vehicular applications is available.
The following are product specific:
• On the IR1101, when plugged into the base, the module is accessible via Cellular 0/1/0, 0/1/1.
• On the IR1101, the module is not supported on the expansion module.
• On the IR1800, the cellular modems are accessible via Cellular 0/4/0, 0/4/1, 0/5/0, 0/5/1.
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
49
