FunctionColorLED
• Green: 4G LTE
• Blue: 5G
RF Band and Port Mapping for the P-5GS6-GL Antenna
The following table lists the RF band mapping for antenna ports.
RF Band Mapping for Antenna Ports:
RXTXTechnologyAntenna
Port
B1, B2, B3, B4, B5, B6, B8, B9, B19B1, B2, B3, B4, B5, B6, B8, B9,
B19
3G
WCDMA
ANT 0
B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17,
B18, B19, B20, B25, B26, B28, B29, B30, B32,
B34, B38, B39, B40, B41, B42, B43, B46, B48,
B66, B71
B1, B2, B3, B4, B5, B7, B8, B12,
B13, B14, B17, B18, B19, B20,
B25, B26, B28, B30, B34, B38,
B39, B40, B41, B66, B71
4G LTE
n1, n2, n3, n5, n7, n8, n12, n20, n25, n28, n38, n40,
n41, n48, n66, n71, n77, n78, n79
n1, n2, n3, n5, n7, n8, n12, n20,
n28, n38, n40, n41, n66, n71
5G NR FR1
B1, B2, B3, B4, B5, B6, B8, B9, B19
—3G
WCDMA
ANT 1
B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17,
B18, B19, B20, B25, B26, B28, B29, B30, B32,
B34, B38, B39, B40, B41, B42, B43, B46, B48,
B66, B71
B5, B20, B42, B43, B48, B714G LTE
n1, n2, n3, n5, n7, n8, n12, n20, n25, n28, n38, n40,
n41, n48, n66, n71, n77, n78, n79
n5, n48, n77, n78, n795G NR FR1
—
—3G
WCDMA
ANT 2
B1, B2, B3, B4, B7, B25, B30, B32, B34, B38,
B39, B40, B41, B42, B43, B46, B48, B66
B1, B2, B3, B4, B7, B41, B664G LTE
n1, n2, n3, n7, n25, n38, n40, n41, n48, n66, n77,
n78, n79
n1, n2, n3, n7, n25, n41, n66,
n77, n78, n79
5G NR FR1
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
52
5G Sub-6 GHz Pluggable Interface Module
RF Band and Port Mapping for the P-5GS6-GL Antenna
