Installing External Antennas
When operating in the 5GHz UNII-1 band, all Omni Directional antennas should be installed vertically, and
all directional antennas should be installed with the main beam aimed parallel to or tilted down toward the
horizon.
Note
The following table shows the external antennas supported by the IW-6300H access point and provides
required quantities for each model.
Table 3: IW-6300H Access Point Supported External Antennas
TypeGainFrequency
Band
Product ID
Omnidirectional, vertically polarized, white4 / 7 dBi2.4 / 5 GHzAIR-ANT2547V-N
Omnidirectional, vertically polarized, gray4 / 7 dBi2.4 / 5 GHzAIR-ANT2547VG-N
Omnidirectional, vertically polarized, white, for
Hazardous Locations
4 / 7 dBi2.4 / 5 GHzAIR-ANT2547V-N-HZ
Omnidirectional, vertically polarized, gray6 / 8 dBi2.4 / 5 GHzAIR-ANT2568VG-N
Directional, dual polarized, 3 port8 / 8 dBi2.4 / 5 GHzAIR-ANT2588P3M-N=
Directional, dual polarized, 4 port13 / 13
dBi
2.4 / 5 GHzAIR-ANT2513P4M-N=
Omnidirectional, vertically polarized, white5 dBi2.4 GHzAIR-ANT2450V-N=
Omnidirectional, vertically polarized, white, for
Hazardous Locations
5 dBi2.4 GHzAIR-ANT2450V-N-HZ=
Omnidirectional, vertically polarized, gray5 dBi2.4 GHzAIR-ANT2450VG-N=
Omnidirectional, horizontally polarized, gray5 dBi2.4 GHzAIR-ANT2450HG-N=
Omnidirectional, vertically polarized8 dBi2.4 GHzAIR-ANT2480V-N=
Directional, dual polarized, 2 port13 dBi2.4 GHzAIR-ANT2413P2M-N=
Omnidirectional, vertically polarized, gray5 dBi5 GHzAIR-ANT5150VG-N=
Omnidirectional, horizontally polarized, gray5 dBi5 GHzAIR-ANT5150HG-N=
Omnidirectional, vertically polarized8 dBi5 GHzAIR-ANT5180V-N=
Directional, dual polarized, 2 port13 dBi5 GHzAIR-ANT5114P2M-N=
For installation instructions and detailed information on any of these antennas, refer to the following antenna
guides:
Installing the Access Point
15
Installing the Access Point
Installing External Antennas
