Rear Panel
The switch rear panel includes StackWise connectors, StackPower or XPS 2200 connectors, ports, fan modules,
and power supply modules.
Figure 11: Catalyst 3850 Switch Rear Panel
StackWise port connector6Ground connector1
StackPower connector7CONSOLE (RJ-45 console port)2
AC OK (input) status LED8MGMT (RJ-45 10/100/1000 management
port)
3
PS OK (output) status LED9RESET button4
Power supply modules (AC power supply
modules shown)
10Fan module5
Catalyst 3850 Switch Hardware Installation Guide
OL-26779-05 23
Product Overview
Rear Panel
