Cisco Catalyst WS-C3850-24T-L User Manual

Figure 12: WS-C3850-12S and WS-C3850-24S Switches Switch Rear Panel
StackWise port connector7Ground connector1
StackPower connector8CONSOLE (RJ-45 console port)2
AC OK (input) status LED9MGMT (RJ-45 10/100/1000 management
port)
3
PS OK (output) status LED10RESET button4
Power supply modules (AC power supply
modules shown)
11BEACON LED5
Fan module6
Catalyst 3850 Switch Hardware Installation Guide
24 OL-26779-05
Product Overview
Rear Panel

Cisco Catalyst WS-C3850-24T-L Specifications

General

Brand	Cisco
Model	Catalyst WS-C3850-24T-L
Category	Switch
Language	English
