E-13
Cisco Physical Security Multiservices Platform Series User Guide
OL-21838-03
Appendix E 16 x D1 and 8 x D1 Video Capture Cards
Specifications
Specifications
Table E-4 lists the physical specifications for the 16 x D1 and 8 x D1 video capture cards.
CIVS-PAN-32BNC BNC breakout panel An optional panel that provides up to 32 BNC
ports for connecting video cameras to video
capture cards. The panel is installed behind the
server and connected to the video capture card
using the multi-channel video cable.
CIVS-CAB-16V Multi-channel video
cable
A DB37 cable that connects the video capture card
to the BNC breakout panel. The cable is 2.5 feet
(76 cm) long and provides connection for up to 16
video ports. The same cable is used with 8 and 16
channel video capture cards.
CIVS-KYBD2232= Serial Port Data
Converter (Generic)
Converts RS-232 serial signals to RS-485/RS-422.
Use this converter when connecting multiple
analog PTZ cameras to the MSP server serial port.
See the
“Connecting and Configuring Analog PTZ
Cameras” section on page E-14 for more
information.
Table E-3 Part Numbers (continued)
PID Item Description
Ta b l e E-4 Specifications for 16 x D1 and 8 x D1 Video Capture Cards
Item Description
Connectivity
Internal connection PCIe (PCI Express) full height, ¾ length
External connection DB37 connector to provide 8 or 16 NTSC or PAL video channels;
this connector is intended to interface to a BNC breakout panel
Physical
Form factor PCIe (PCI Express) full height, ¾ length
Length 10.03 inches (254.76 mm)
Height 3.87 inches (98.30 mm)
Bracket Standard bracket plus additional gold finger tab
Power and environmental requirements
Power 12VDC +/– 20%
24 W typical, 29 W maximum
Operating temperature 50° to 95°F (10° to 35°C)
Non-operating temperature –40° to 158°F (–40° to 70°C)
Operating relative humidity 8% to 90% (non-condensing)
Non-operating relative humidity 5% to 95% (non-condensing)
Required airflow 140 LFM
