Rack-Mount the Chassis
This procedure describes how to install the Firepower 4100 series security appliance in a rack using the rack
kit that shipped with the chassis.
The rack is a standard Electronic Industries Association (EIA) rack. It is a 4-post-EIA-310-D, which is the
current revision as specified by EIA. The vertical hole spacing alternates at .50 inches (12.70 mm) to .625
inches (15.90 mm) to .625 inches (15.90 mm) and repeats. The start and stop space is in the middle of the
.50-inch holes. The horizontal spacing is 18.312 inches (465.1 mm), and the rack opening is specified as a
minimum of 17.75 inches (450 mm).
You need the following to install the chassis in a rack (4-post EIA-310-D rack):
• #1 Phillips screwdriver
• Firepower 4100 rack-mount kit that contains the slide rails, mounting ears, and screws
Slide rail assemblies work with 4-post racks and cabinets with square slots, round 7.1-mm holes and 10-32-inch
threaded holes on the rack post front. The slide rail works with front to back spacing of rack posts from 24 to
36 inches. The rack-mounting posts need to be 2 to 3.5 mm thick to work with the slide rail rack mounting.
Internal obstructions between rails can make slide rail installation more complicated. Use racks that do not
have internal obstructions between rails for unhindered slide rail installation.
Note
Safety Warnings
Take note of the following warnings:
Statement 1006—Chassis Warning for Rack-Mounting and Servicing
To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions
to ensure that the system remains stable. The following guidelines are provided to ensure your safety:
• This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
• When mounting this unit in a partially filled rack, load the rack from the bottom to the top with the
heaviest component at the bottom of the rack.
• If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing
the unit in the rack.
Warning
Statement 1018—Supply Circuit
To reduce risk of electric shock and fire, take care when connecting units to the supply circuit so that
wiring is not overloaded.
Warning
Cisco Firepower 4110, 4120, 4140, and 4150 Hardware Installation Guide
48
