Cisco IW3702 User Manual

Examples of Access Point and Antenna Deployment Configurations
The section provides examples of antenna installation configurations, including applicable accessories such as cables, lighting arrestors,
and adapters.
Indoor or Outdoor Cisco Aironet Dual-Band Omnidirectional Antenna and Access Point
Table 7: Indoor or Outdoor Dual-Band Omnidirectional Antenna and Access Point
DescriptionItem
4 x Cisco Aironet dual-band AIR-ANT2547V-N or
AIR-ANT2547VG-N omnidirectional antennas directly
connected to access point antenna connectors.
Antenna Arrangement
IW3702-2E-UXK9 or IW3702-2E-x-K9
Do not use this configuration with the
IW3702-4E-UXK9 or IW3702-4E-x-K9 model. For
the -4E models, all four antenna ports are on one side,
and would be too close to each other for optimal
MIMO IEEE 802.11ac operation if attached antennas
directly to all 4 ports.
Note
Access Point
N/AIndoor Cable
N/AAdapter and/or Lightning Arrestor
N/AOutdoor Cable
Select from:
•
White model, Cisco PID
3
AIR-ANT2547V-N
•
Grey Model, Cisco PID AIR-ANT2547VG-N
4 x Cisco Aironet dual-band omnidirectional antennas are
required.
The antenna specifications are:
• 2400–2484MHz, 5150–5875MHz, dual-band, WiFi,
operating frequency range
•
4 dBi (2.4 GHz), 7 dBi (5 GHz) gain
•
11 in. (27.94 cm) stick antennas for indoor or outdoor
use with a type N(m) connector
•
IP67 rated, -40 to 185°F (-40°C to 85°C) operating
temperature range
Antenna
3
PID = Product identifier code.
28
