NonePrerequisite Procedures

RequiredRequired/As Needed

OnsiteOnsite/Remote

NoneSecurity Level

Procedure

Step 1 Remove the dust plug from the fiber adapter.

Step 2 Insert a CLETOP stick swab (14100400) into the adapter opening and rotate the swab.

Step 3 Place dust plugs on the fiber adapters when not in use.

Step 4 Return to your originating procedure (NTP).

NTP-G40 Replace the Front Door

This procedure replaces the front door and door ground strap after installing cards

and fiber-optic cables.

Purpose

#2 Phillips screwdriver

Medium slot-head screwdriver

Small slot-head screwdriver

Tools/Equipment

NTP-G259 Open and Remove the Standard Door of the ONS 15454 M6 ShelfPrerequisite Procedures

RequiredRequired/As Needed

OnsiteOnsite/Remote

NoneSecurity Level

Be careful not to crimp any fiber cables that are connected to the MXP/TXP cards or DWDM cards. Some

might not have the fiber boot attached.

Note

Procedure

Step 1 Insert the front door into the hinges on the shelf assembly.

Step 2 (ANSI only) Attach one end of the ground strap terminal lug (72-3622-01) to the male stud on the inside of

the door. Attach and tighten the #6 Kepnut (49-0600-01) using the open-end wrench.

Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf

NTP-G40 Replace the Front Door

Cisco ONS 15454 M12 User Manual
