NTP-G260 Replace the Fan-Tray Assembly of the ONS 15454 M6
Shelf Assembly
This procedure replaces the fan-tray assembly of the ONS 15454 M6 shelf
assembly.
Purpose
Small slot-head screwdriverTools/Equipment
NTP-G257 Install the Fan-Tray Assembly in the ONS 15454 M6 ShelfPrerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Do not force a fan-tray assembly into place. Doing so can damage either the connectors on the fan tray or the
connectors on the back panel of the shelf assembly, or both.
Caution
The estimated time required to change a fan-tray assembly is 2 minutes.
Note
Procedure
Step 1 Open the front door of the shelf assembly (see DLP-G576 Open the Standard Door of the ONS 15454 M6
Shelf ). If the shelf assembly does not have a front door, continue with Step 3.
Step 2 (Optional) Complete the DLP-G577 Remove the Standard Door of the ONS 15454 M6 Shelf to remove the
front door. If you do not want to remove the door, proceed to Step 3.
Step 3 Untighten the screws on the fan-tray assembly (see the following figure).
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
24
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G260 Replace the Fan-Tray Assembly of the ONS 15454 M6 Shelf Assembly
