Cisco UCS C220 M3 Installation And Service Guide

C-7
Cisco UCS C220 Server Installation and Service Guide
OL-25760-01
Appendix C RAID Controller Considerations
Embedded MegaRAID Controller
Embedded MegaRAID Controller
Note VMware ESX/ESXi or any other virtualized environments are not supported for use with the embedded
MegaRAID controller. Hypervisors such as Hyper-V, Xen, or KVM are also not supported for use with
the embedded MegaRAID controller.
This server includes the option for an embedded MegaRAID controller with two mini-SAS connectors
on the motherboard.
• The default setting for this embedded controller is SAS RAID 0, 1, and 10 support for up to four
SATA drives.
• You can upgrade this to support to SAS RAID 0, 1, and 10 support for up to eight SAS drives by
installing a Storage Controller Unit (SCU) upgrade ROM chip on the motherboard. See Installing a
SCU Upgrade ROM Module For Embedded RAID SAS Support, page C-9.
• You can further upgrade this support by adding SAS RAID 5 support with an optional software key.
See Installing a Software RAID Key Module for Embedded RAID 5 Support, page C-10.
• When you order the server with this controller, the controller is enabled in the BIOS. Instructions
for enabling the controller are included for the case in which a server is reset to defaults (Disabled).
See Enabling the Embedded RAID Controller in the BIOS, page C-10.
Note You cannot downgrade from using a RAID controller card to using the embedded controller (see RAID
Controller Migration, page C-6). Instructions for installing upgrade modules and enabling the embedded
controller in the BIOS are included here for those upgrading a server with no RAID controller or drives.
Caution Data migration from SW RAID (embedded RAID) to HW RAID (a controller card) is not supported and
could result in data loss. Migrations from SW RAID to HW RAID are supported only before there is data
on the drives, or the case in which there are no drives in the server (see RAID Controller Migration,
page C-6).
• You can migrate from using the embedded controller to using a RAID card only before there is data
on the drives. In this case, you must disable the embedded controller. See Disabling the Embedded
RAID Controller in the BIOS, page C-11.
• The required drivers for this controller are already installed and ready to use with the LSI SWRAID
Configuration Utility. However, if you will use this controller with Windows or Linux, you must
download and install additional drivers for those operating systems. See Installing LSI MegaSR
Drivers For Windows and Linux, page C-11.
This section contains the following topics:
• Notes on Supported Embedded MegaRAID Levels, page C-8
• Installing a SCU Upgrade ROM Module For Embedded RAID SAS Support, page C-9
• Installing a Software RAID Key Module for Embedded RAID 5 Support, page C-10
• Enabling the Embedded RAID Controller in the BIOS, page C-10
• Disabling the Embedded RAID Controller in the BIOS, page C-11
• Launching the LSI Embedded RAID Configuration Utility, page C-11
• Installing LSI MegaSR Drivers For Windows and Linux, page C-11

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	724 mm
Width	430 mm
Height	43.2 mm
