Cisco UCS C220 M3 Installation And Service Guide

C-12
Cisco UCS C220 Server Installation and Service Guide
OL-25760-01
Appendix C RAID Controller Considerations
Embedded MegaRAID Controller
Downloading the LSI MegaSR Drivers
The MegaSR drivers are included in the C-series driver ISO for your server and OS. Download the
drivers from Cisco.com:
Step 1 Find the drivers ISO file download for your server online and download it to a temporary location on
your workstation:
a. See the following URL: http://www.cisco.com/cisco/software/navigator.html
b. Click Unified Computing and Servers in the middle column.
c. Click Cisco UCS C-Series Rack-Mount Standalone Server Software in the right-hand column.
d. Click your model of server in the right-hand column.
e. Click Unified Computing System (UCS) Drivers.
f. Click the release number that you are downloading.
g. Click Download to download the drivers ISO file.
h. Verify the information on the next page, then click Proceed With Download.
i. Continue through the subsequent screens to accept the license agreement and then browse to a
location where you want to save the drivers ISO file.
Microsoft Windows Driver Installation
This section explains the steps to install the LSI MegaSR driver in a Windows installation.
This section contains the following topics:
• Windows Server 2008R2 Driver Installation, page C-12
• Updating the Windows Driver, page C-13
• Linux Driver Installation, page C-14
Windows Server 2008R2 Driver Installation
Perform the following steps to install the LSI MegaSR device driver in a new Windows Server 2008R2
operating system. The Windows operating system automatically adds the driver to the registry and copies
the driver to the appropriate directory.
Step 1 Create a RAID drive group using the LSI SWRAID Configuration utility before you install this driver
for Windows. Launch this utility by pressing Ctrl+M when LSI SWRAID is shown during BIOS post.
Step 2 Download the Cisco UCS C-Series drivers ISO, as described in Downloading the LSI MegaSR Drivers,
page C-12.
Step 3 Prepare the drivers on a USB thumb drive:
a. Burn the ISO image to a disc.
b. Browse the contents of the drivers folders to the location of the embedded MegaRAID drivers:
/<OS>/Storage/Intel/C600/
c. Expand the Zip file, which contains the folder with the MegaSR driver files.
d. Copy the expanded folder to a USB thumb drive.

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	724 mm
Width	430 mm
Height	43.2 mm
