Cisco UCS C220 M4 Service Manual

C-4
Cisco UCS C220 M4 Server Installation and Service Guide
OL-32473-01
Appendix C RAID Controller Considerations
Cisco UCS SAS 9300-8e HBA Considerations
Cisco UCS SAS 9300-8e HBA Considerations
This section contains the following topics:
• Mixing Rules, page C-4
• Bad Drive and Predictive Failure Behavior, page C-4
• Setting the Preferred Boot Device, page C-4
Mixing Rules
Do not mix the Cisco UCS 9300-8e HBA in the same server as the Cisco UCS 12G SAS Modular HBA.
Bad Drive and Predictive Failure Behavior
The bad drive and predictive failure behavior for the Cisco UCS SAS 9300-e HBA cards is different than
that for LSI MegaRAID cards. The list below compares behavior for these HBA cards and LSI
MegaRAID cards.
• Bad/invalid/0MB drive handling:
– MegaRAID: The bad drive is marked BAD in the GUI/CLI interfaces and the fault LED on the
drive is solid amber.
– HBA: The bad drive is not shown in the GUI/CLI and there is no LED indication.
• Drive predictive failure:
– MegaRAID: If the drive is part of a RAID volume with a spare, the software performs an
auto-copy backup and then marks the drive failed/BAD with the fault LED on the drive solid
amber.
– HBA: There is no error handling and there is no LED indication. The operating system must
handle the fault.
Setting the Preferred Boot Device
Currently, the boot device order for these HBAs does not map to a physical slot as seen in the Boot
Option dialog of the server BIOS Setup Utility. This makes it difficult to differentiate between multiple
devices.
Use the following procedure to select the preferred boot device in the LSI BIOS CU SAS Topology
screen. When you select the preferred boot device in the BIOS CU SAS Topology screen, it is displayed
at the top of the list in the server BIOS Setup Utility Boot Option dialog, making it easy to identify.
Step 1 In the LSI SAS BIOS CU, navigate to the SAS Topology screen.
Step 2 Press Alt+B to select or deselect a device as the preferred boot device. On this screen, you can identify
the device by slot number.
Step 3 Press Alt+A to select or deselect a device as the alternate boot device. On this screen, you can identify
the device by slot number. The alternate boot device is used if the preferred boot device is not detected.
Step 4 Return to the BIOS CU SAS Topology screen.

Cisco UCS C220 M4 Specifications

General

Tcase	78.9 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR1YA
Processor cache	25 MB
Processor cores	10
System bus rate	9.6 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	20
Processor codename	Haswell
Motherboard chipset	Intel C610
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	3 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	105 W
Compatible processor series	Intel® Xeon®
Supported processor sockets	LGA 2011-v3 (Socket R)
Number of processors installed	2
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID levels	0, 1, 5, 6, 10, 50, 60, JBOD
HDD interface	-
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Memory slots	24
Internal memory	16 GB
Memory clock speed	2133 MHz
Maximum internal memory	384 GB
Maximum graphics card memory	8 MB
Graphics card	G200e
Graphics card family	Matrox
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
PCI Express slots version	3.0
Processor ARK ID	81705
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Power supply	770 W
Power supply input frequency	50 - 60 Hz
Chassis type	Rack (1U)
Trusted Platform Module (TPM) version	1.2
Compatible operating systems	Microsoft Windows Server 2012 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2008 R2 Red Hat Enterprise Linux Novell SUSE Linux Enterprise Server Oracle Linux (Unbreakable Enterprise Kernel (UEK)) Oracle Solaris Ubuntu Server CentOS

Weight and Dimensions

Depth	756 mm
Width	430 mm
Height	43.2 mm
