Cisco UCS C220 Installation And Service Guide

C-5
Cisco UCS C220 Server Installation and Service Guide
OL-25760-01
Appendix C RAID Controller Considerations
Factory-Default Option ROM Settings
Factory-Default Option ROM Settings
Table C-4 describes the option ROM (OPROM) settings for card slots that are made at the factory for
various configurations. The version of the se
rver and the number of CPUs affect the OPROM settings.
Note If an option is listed as “not allowed” in Table C-4, that is because it is not supported in the particular
configuration described in that table row. See the footnotes below the table for more information.
For additional information about RAID controller support, see Supported RAID Controllers and
Required Cables, page C-2.
Ta b l e C-4 Cisco UCS C220 Factory-Default Option ROM Settings
Server Version
Number
of CPUs
Embedded
SW
RAID
Enabled?
Mezz. RAID
Controller
Installed?
PCIe RAID
Controller 1
Installed?
PCIe RAID
Controller 2
Installed?
LOM
por
ts Comments
C220 SFF 8 HDD/
C2
20 LFF 4 HDD
1 Enabled Not allowed
1
1. You cannot use the embedded SW RAID and HW RAID (mezzanine or PCIe card) at the same time.
Not allowed Not allowed Always
enabled
All other OPROM
is disabled.
C220 SFF 8 HDD/
C2
20 LFF 4 HDD
1 Not allowed Not allowed
2
2. In single-CPU configurations, the mezzanine card slot is not supported.
Installed: 
PCIe slot 1
enabled
3
3. In single-CPU configurations, PCIe slot 2 is not available.
Not allowed Always
enabled
All other OPROM
is disabled.
C220 SFF 8 HDD/
C2
20 LFF 4 HDD
2 Enabled Not allowed Not allowed Not allowed Always
enabled
All other OPROM
is disabled.
C220 SFF 8 HDD/
C2
20 LFF 4 HDD
2 Not allowed Installed: 
connector
en
abled
Not allowed
4
4. You cannot mix controller types in a server. A PCIe-style controller cannot be used when a mezzanine-style controller is used.
Not allowed Always
enabled
All other OPROM
is disabled.
C220 SFF 8 HDD/
C2
20 LFF 4 HDD
2 Not allowed Not allowed
5
5. You cannot mix controller types in a server. A mezzanine-style controller cannot be used when a PCIe-style controller is used.
Installed: 
PCIe slot 2
en
abled
Not allowed Always
en
abled
All other OPROM
is disabled.
