APPENDIX B
Connector and Cable Specifications
This appendix contains these topics:
•
Connector Specifications, page 45
•
Cables and Adapters, page 46
Connector Specifications
10/100/1000 Ports (Including PoE)
All 10/100/1000 ports use standard RJ-45 connectors and Ethernet pinouts.
Figure 23: 10/100/1000 Port Pinouts
Cisco Catalyst 2960-L Series 24-Port and 48-Port Switch Hardware Installation Guide
45
