Cisco XR 12000 Series Installation Guide

42
Cisco XR 12000 Series Router Ethernet Line Card Installation
OL-7861-01
Cabling and Specifications
Step 2 Attach the line card cable-management bracket to the line card as follows:
a. Position the cable-management bracket over the front of the line card faceplate.
b. Insert and tighten the captive screw(s) to secure the bracket to the line card.
c. Starting with the bottom port on the line card, connect each interface cable to the intended port.
Step 3 For multiport line card cable-management brackets, carefully wrap the cables with the supplied Velcro
strap. (See Figure 32.)
For single-port line card cable-management brackets, carefully press the interface cable onto the cable
clip. (See Figure 33.) Avoid any kinks or sharp bends in the cable.
For information on disconnecting and connecting interface cables, see the “Removing and Installing
Fiber-Optic Interface Cables” section on page 52.
Cabling and Specifications
The following sections provide information about specifications and cabling for Ethernet line cards:
• Fast Ethernet Interface, page 42
• Gigabit Ethernet Interface, page 44
• Fiber-Optic Interface Cables, page 50
• Removing and Installing Fiber-Optic Interface Cables, page 52
• Cleaning Fiber-Optic Connectors, page 56
• Type RJ-45 100BASE-T Copper Cables, page 57
• Removing and Installing RJ-45 100BASE-T Copper Cable, page 57
Fast Ethernet Interface
The term Ethernet is commonly used for all carrier sense, multiple access/collision detection
(CSMA/CD) local-area networks (LANs) that conform to Ethernet specifications, including Fast
Ethernet defined by IEEE 802.3u.
IEEE 802.3u specifies the following different physical layers for 100BASE-T:
• 100BASE-TX—100BASE-T, half- and full-duplex over Category 5 unshielded twisted-pair (UTP),
Electronics Industry Association/Telecommunications Industry Association
[EIA/TIA]–568-compliant cable.
Note The 8-Port Fast Ethernet line card provides an RJ-45 connector that follows the
Media-Dependent Interface (MDI) port wiring standard, as opposed to the
Media-Dependent Interface-crossed (MDI-X) wiring scheme found on many hubs and
repeaters.
