CITIZEN Android Label Print SDK — Programming Manual
14
2. API specification
2.1. Return value
Return value
Description
CLS_SUCCESS (0)
The operation has been done successfully.
CLS_E_CONNECTED (1001)
The printer is already connected.
CLS_E_DISCONNECT (1002)
The printer is not connected.
CLS_E_NOTCONNECT (1003)
Failed to connect to the printer.
CLS_E_CONNECT_NOTFOUND (1004)
Failed to confirm the model name after connecting to the printer.
CLS_E_NOCONTEXT (1006)
No context is specified.
CLS_E_BT_DISABLE (1007)
The Bluetooth device setting is invalid.
CLS_E_BT_NODEVICE (1008)
The Bluetooth device is not found.
CLS_E_ILLEGAL (1101)
The operation is not supported by the printer or an invalid parameter
was used.
CLS_E_OFFLINE (1102)
The printer is offline.
CLS_E_NOEXIST (1103)
The file name does not exist.
CLS_E_FAILURE (1104)
The service could not perform the requested procedure.
CLS_E_TIMEOUT (1105)
The service has been timed out waiting for a response from the printer.
CLS_E_NO_LIST (1106)
A printer could not be found for the printer search.
CLS_EPTR_BADFORMAT (1203)
The file format is not supported.

Citizen CL-S521 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 DPI
PC connected	Yes
Standard interfaces	USB 1.1, Serial
Optional connectivity	Ethernet, Serial (RS-232)
USB 1.1 ports quantity	1
Connectivity technology	Wired
Flash memory	4 MB
Internal memory	16 MB
Compatible operating systems	Windows 7/XP/2003/2008/Vista
Form factor	Desktop
Core diameter	25 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	1625.6 mm
Maximum roll diameter	125 mm
Supported paper width	12.5 - 118.1 mm
Media thickness (imperial)	0.0025 - 0.01 \
Supported paper width (imperial)	0.50 - 4.65 \
Product color	Gray
Housing material	Metal, Plastic

Weight and Dimensions

Depth	289 mm
Width	231 mm
Height	183 mm
Weight	3600 g
