Citizen CL-S521 Programming Manual

CITIZEN Android Label Print SDK — Programming Manual
45
2.2.28 StopOffset property
Syntax
int StopOffset
Attribute
Read/Write
Description
Specifies the distance between paper sensor and cutter or peeler to change the print stop position.
Note that the initial values are calculated to stop paper at an appropriate position. An insufficient
value truncates the printed label, an exceeded value truncates the next label.
Media handling
Inch system
Metric system
Initial
value
Minimum
value
Max
value
Initial
value
Minimum
value
Max
value
None
0000
0000
9999
0000
0000
9999
Cutter
0100
0254
Peel Off
0050
0127
Tear Off
0070
0178
*0.01 inches or 0.1 mm
Setter method
int setStopOffset (int stopOffset)
Returns CLS_SUCCESS (0) on success. See "2.1 Return value" for the error codes.
Getter method
int getStopOffset ()
Returns the set value. If nothing has been set, it returns CLS_PROPERTY_DEFAULT(999999).
Example
int stopOffset;
printer.setStopOffset(240);
stopOffset = printer.getStopOffset();

Citizen CL-S521 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 DPI
PC connected	Yes
Standard interfaces	USB 1.1, Serial
Optional connectivity	Ethernet, Serial (RS-232)
USB 1.1 ports quantity	1
Connectivity technology	Wired
Flash memory	4 MB
Internal memory	16 MB
Compatible operating systems	Windows 7/XP/2003/2008/Vista
Form factor	Desktop
Core diameter	25 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	1625.6 mm
Maximum roll diameter	125 mm
Supported paper width	12.5 - 118.1 mm
Media thickness (imperial)	0.0025 - 0.01 \
Supported paper width (imperial)	0.50 - 4.65 \
Product color	Gray
Housing material	Metal, Plastic

Weight and Dimensions

Depth	289 mm
Width	231 mm
Height	183 mm
Weight	3600 g
