Clarion CX501 Service Manual

-10-
CX501/CX501B/CX501A
ELECTRICAL PARTS LIST
Main PWB(B1) section
Note)1. Some parts depend on each model.
The model name is specified in the description.
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ANT201 092-4000-51
ANTENNA RECEPT
C214 168-1052-78 16V 1uF C420 187-2263-35 16V 22uF
C101 187-1073-35 16V 100uF C215 168-1032-55 0.01uF K C421 043-1735-90 100
p
FCH
C102 187-1073-35 16V 100uF C216 168-1032-55 0.01uF K C422 043-1735-90 100pF CH
C103 043-1735-90 100
p
F CH C217 168-1042-78 16V 0.1uF C423 043-1735-90 100
p
FCH
C104 043-1835-90 3900pF C218 168-2242-58 0.22uF B C424 043-1735-90 100pF CH
C105 043-1619-90 0.068uF C219 168-2232-55 0.022uF K C425 178-4742-78 0.47uF
C106 168-1022-55 1000pF K C220 177-1062-78 10pF C426 187-1053-65 50V 1uF
C107 043-1735-90 100
p
F CH C221 168-1042-78 16V 0.1uF C427 172-1041-11 0.1uF
C108 189-1083-32 16V 1000uF C222 168-1042-78 16V 0.1uF C428 042-1447-00 16V 2200uF
C109 043-1719-90 22
p
F CH C223 166-1201-50 12
p
F CH D100 001-4301-41 HZU 7.5B2
C110 043-1802-90 0.01uF C247 166-1201-50 12
p
F CH D101 001-1323-90 L1SS355T1G
C111 043-1719-90 22pF CH C249 168-1042-78 16V 0.1uF D106 001-1310-00 KDS160-RTK
C112 042-1577-00 6.3V 100uF C301 043-1838-90 4700
p
F D107 001-4301-26 HZU4.7B2
C113 168-1042-78 16V 0.1uF C302 043-1841-90 0.047uF D109 001-0466-61 1A4
C114 168-3332-78 0.033uF K C303 043-1838-90 4700
p
F D110 001-4301-26 HZU4.7B2
C115 168-1042-78 16V 0.1uF C304 187-1063-35 16V 10uF D111 001-0466-61 1A4
C116 187-1073-35 16V 100uF C305 187-1063-35 16V 10uF D112 001-1310-00 KDS160-RTK
C117 043-1802-90 0.01uF C308 187-1053-65 50V 1uF D113 001-1310-00 KDS160-RTK
C118 043-1802-90 0.01uF C309 187-1053-65 50V 1uF D121 001-0466-61 1A4
C119 043-1800-90 1000
p
F C310 187-1053-65 50V 1uF D160 001-1310-00 KDS160-RTK
C120 168-1032-55 0.01uF K C311 187-1053-65 50V 1uF D203 001-2630-90 1SS420-TPL3,F
C121 187-2253-65 50V 2.2uF C314 187-1063-35 16V 10uF D303 001-4316-17 LM3Z4V3T1G
C123 043-1804-90 0.1uF C315 187-1063-35 16V 10uF D401 001-4316-24 LM3Z8V2T1G
C124 187-2273-15 6.3V 220uF C316 187-1063-35 16V 10uF D403 001-1310-00 KDS160-RTK
C125 043-1735-90 100
p
F CH C317 187-1063-35 16V 10uF D404 001-1310-00 KDS160-RTK
C126 187-1063-35 16V 10uF C318 187-1063-35 16V 10uF D405 001-1310-00 KDS160-RTK
C127 187-2253-65 50V 2.2uF C319 187-1063-35 16V 10uF D406 001-0592-61 1N5404
C128 187-1063-35 16V 10uF C320 043-1804-90 0.1uF D601 001-0529-20 MA8039-L
C129 187-1053-65 50V 1uF C321 043-1804-90 0.1uF IC101 -----------------
LC88F40HOPAU-QIP
C130 043-1735-90 100pF CH C322 187-4763-15 6.3V 47uF
(Software should be
C131 043-1841-90 0.047uF C324 043-1723-90 33
p
F CH wrritten on
C132 043-1804-90 0.1uF C325 043-1804-90 0.1uF production)
C133 187-1073-35 16V 100uF C326 043-1804-90 0.1uF
(
034900-052
)
C134 187-1073-35 16V 100uF C327 043-1804-90 0.1uF IC102 051-3218-90 TA76431F
C135 187-3363-45 25V 33uF C328 043-1804-90 0.1uF IC103 -----------------
24LC256I-SN
C136 187-1063-35 16V 10uF C329 187-1063-35 16V 10uF
(E2PROM Data
C138 187-1063-35 16V 10uF C330 043-1804-90 0.1uF
should be wrritten on
C139 187-1063-35 16V 10uF C331 043-1800-90 1000
p
F
production)
C140 168-2242-58 0.22uF B C333 187-1063-35 16V 10uF (942990-051)
C141 043-1804-90 0.1uF C334 187-1063-35 16V 10uF IC104 051-5438-08 S-80830CN
C145 043-1802-90 0.01uF C335 187-1063-35 16V 10uF IC105 051-5437-58 R3111N211A
C147 187-1053-65 50V 1uF C336 043-1804-90 0.1uF IC106 051-3535-90 MM3144ANRE
C148 043-1804-90 0.1uF C337 043-1804-90 0.1uF IC107 051-3730-00 LV5680P
C149 043-1804-90 0.1uF C338 187-4763-35 16V 47uF IC108 051-3577-90
S-1206B33-U3TIG
C150 043-1804-90 0.1uF C339 043-1735-90 100
p
F CH IC201 051-4028-90 TEF6606
C151 165-1063-35 16V 10uF C340 043-1735-90 100pF CH IC301 051-3060-90 AZ4558M
C152 043-1804-90 0.1uF C341 187-1053-65 50V 1uF IC302 051-5048-90 NJW1222
C153 168-2242-58 0.22uF B C342 187-1053-65 50V 1uF IC303 051-3060-90 AZ4558M
C154 187-1063-35 16V 10uF C343 043-1735-90 100
p
F CH IC307 051-3059-90 NJM2120M
C156 168-2242-58 0.22uF B C344 043-1735-90 100
p
F CH IC402 051-2074-00 LV47017P
C157 187-1063-35 16V 10uF C345 043-1735-90 100
p
F CH J100 075-0393-50 3P
C158 168-2242-58 0.22uF B C346 043-1735-90 100
p
F CH J102 076-0648-22 22P
C159 168-2242-58 0.22uF B C360 043-1819-90 2200pF J105 074-2226-90 40P
C160 187-1063-35 16V 10uF C361 043-1819-90 2200
p
F J301 076-0648-22 22P
C161 168-2242-58 0.22uF B C364 043-1806-90 1pF J401 074-1214-50 16P
C162 165-1063-35 16V 10uF C365 043-1806-90 1
p
F L102 010-3100-66 2.2uH
C201 166-2096-50 2pF CK C366 043-1715-90 15pF CH L103 010-3100-66 2.2uH
C202 166-2201-50 22
p
F CH C367 043-1806-90 1
p
F L104 010-3100-66 2.2uH
C203 168-1022-55 1000
p
F K C370 187-4763-15 6.3V 47uF L105 010-3407-59 5.6uH J
C204 168-1022-55 1000
p
F K C371 187-1073-35 16V 100uF L106 010-3105-67
1.5k ohm/100kHz
C205 166-1201-50 12
p
F CH C372 187-2273-15 6.3V 220uF L201 010-2003-04 30uH
C206 168-1032-55 0.01uF K C409 178-4742-78 0.47uF L202 010-3406-50 1uH J
C207 168-1032-55 0.01uF K C410 178-4742-78 0.47uF L203 010-3406-53 1.8uH J
C208 168-1052-78 16V 1uF C411 178-4742-78 0.47uF L204 010-3406-43 0.27uH J
C209 168-2242-58 0.22uF B C412 178-4742-78 0.47uF L205 010-3062-54 LQH31HNR2
C210 166-1501-50 15
p
F CH C415 187-1063-35 16V 10uF L206 010-4054-00
#886ANS-0904QH
C211 166-3901-50 39
p
F CH C417 187-1063-35 16V 10uF L207 010-3072-90 560uH
C212 168-2242-58 0.22uF B C418 187-1063-35 16V 10uF L208 010-3072-90 560uH
C213 168-1042-78 16V 0.1uF C419 187-1063-35 16V 10uF L209 010-3105-62 1k ohm/100MHz

Clarion CX501 Specifications

General

MP3 playback	Yes
Product color	Black
Volume control	Digital
USB version	2.0
Bluetooth profiles	A2DP, AVRCP, HFP, HSP, OPP, PBAP
USB ports quantity	1
Amplifier output power	200 W
Key illumination color	Blue
